Description
The Hikvision DS-2CE16D0T-LPFS is a versatile 2 MP Fixed Mini Bullet Camera designed to provide clear, dependable surveillance in any lighting condition. Equipped with a 2 MP CMOS sensor, it captures crisp Full HD video at a resolution of 1920 × 1080, ensuring detailed monitoring for homes, offices, retail stores, and commercial properties.
One of its standout features is Smart Hybrid Light technology, which intelligently switches between infrared and white light modes to optimize nighttime visibility. The camera offers up to 25 meters of IR illumination and up to 20 meters of white light coverage, delivering bright and detailed images even in low-light environments.
The built-in microphone supports audio over coaxial cable, allowing synchronized audio and video transmission through a single cable. This added audio capability enhances situational awareness and provides more comprehensive security monitoring.
Available with 2.8 mm and 3.6 mm fixed focal lenses, the DS-2CE16D0T-LPFS provides flexible viewing angles to suit various surveillance applications. It also supports four switchable video formats—TVI, AHD, CVI, and CVBS—ensuring compatibility with a wide range of DVR systems.
Built with an IP67-rated weatherproof housing, the camera is resistant to dust, water, and harsh environmental conditions, making it suitable for both indoor and outdoor installations.
Key Features
- 2 MP Full HD (1920 × 1080) resolution
- Smart Hybrid Light technology
- Built-in microphone with audio over coax support
- Up to 25 m infrared night vision
- Up to 20 m white light illumination
- Available in 2.8 mm and 3.6 mm fixed lens options
- Supports TVI, AHD, CVI, and CVBS outputs
- Digital WDR, BLC, and HLC image enhancement
- IP67-rated weatherproof protection
- Suitable for residential and commercial surveillance applications
- Compatible with Hikvision and supported analog DVR systems
The Hikvision DS-2CE16D0T-LPFS combines Full HD video, integrated audio, and intelligent dual-light technology in a compact and durable design, making it an excellent choice for modern security installations.
| Specification | Details |
|---|---|
| Model | DS-2CE16D0T-LPFS |
| Camera Type | 2 MP Dual Light Audio Fixed Mini Bullet Camera |
| Image Sensor | 2 MP CMOS |
| Maximum Resolution | 1920 × 1080 |
| Minimum Illumination | 0.01 Lux @ F1.6, 0 Lux with IR |
| Lens Options | 2.8 mm / 3.6 mm |
| IR Range | Up to 25 m |
| White Light Range | Up to 20 m |
| Supplement Light Type | Smart Hybrid Light, IR, White Light |
| Audio | Built-in Microphone (Audio over Coax) |
| Audio Pickup Distance | Up to 5 m |
| Day & Night Mode | Auto / Color |
| Video Output | TVI / AHD / CVI / CVBS |
| Frame Rate | Up to 1080p @ 30 fps |
| WDR | Digital WDR |
| Image Enhancement | DWDR, BLC, HLC, Global |
| White Balance | Auto / Manual |
| AGC | Supported |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
| Protection Rating | IP67 |
| Material | Plastic |
| Power Supply | 12 VDC ±25% |
| Power Consumption | Max. 3.3 W |
| Operating Temperature | -40°C to 60°C |
| Dimensions | 138.8 × 60.9 × 57.9 mm |
| Weight | Approx. 155 g |
| Communication | HIKVISION-C |
| Optional Accessory | DS-1280ZJ-XS Junction Box |
